INTRODUCTION

ETCR8610 Leakage Protector(RCD) Tester is designed for on-site inspecting of the three-pole sockets working status and testing the leakage protector(RCD) leakage action time. The test current with 6 gears (10mA, 15mA, 20mA, 25mA, 30mA, 35mA) from 10~35mA, and the test leakage current action time range is 0.001s~1.000s. When testing, insert the three-pole plug of the tester into the three-pole socket. The indicator lights A, B, and C of the tester will show the working status of the socket and whether the wiring connection is correct, and the tester will display the testing leakage current action time. The tester is portable, small size, light weight, exquisite appearance, and easy to carry, which is an ideal tool for on-site or indoor testing of various leakage protectors(RCD).

Technical Specification

Function

Check the working status of the socket and test the leakage action time of the leakage protector

Power Supply

DC9V, alkaline dry battery (6LR61 9V)

Display Mode

4-digit LCD backlight display

LCD Size

35mmX21.5mm;

Display area: 32mmX15mm

Rated voltage

AC 220V

Leakage current grade

10mA,15mA, 20mA, 25mA, 30mA, 35mA

Leakage Current Action Time Range

0.001s~1.000s

Leakage Current Action Time Accuracy

±5%rdg±3dgt

Grade Current Accuracy

±10%rdg±2dgt

ABC Indicator

Socket working status indicator

TESTING

Indicator

Flashing during the test

Meter Dimension

140mmX70mmX50mm

Meter Weight

About 300g (include battery);

Total weight: about 1kg (include accessories)

Battery Voltage

When the battery power is low, the low battery voltage symbol is displayed to remind you to replace the battery.

Working Current

Standby 6mA MAX, test 40mA MAX

Working Temperature and Humidity

-10℃~40℃; below 80%RH

Storage Temperature and Humidity

-10℃~60℃; below 70%RH

Insulation strength

100MΩ or greater, AC2kV/rms (between case and screw)

Suitable Safety Standard

IEC1010-1, IEC1010-2-032,

Pollution level 2, CAT Ⅲ (600V) IEC61326 (EMC standard)
