Xtester-SL7-63-Brand Suntree Adjustable Dc Mcb 32 Amp 30a 6A~ 63A Manufacturers

2025-07-29 15:02:10

Xtester-SL7-63-Brand Suntree Adjustable Dc Mcb 32 Amp 30a 6A~ 63A Manufacturers

Main Features :
Serial No. : monica0938

Specification

Contact Us For Quotation

Email: 464560351@qq.com

Whatsapp&Wechat:+8618620373879

Xtester-SL7-63-Brand Suntree Adjustable Dc Mcb 32 Amp 30a 6A~ 63A Manufacturers

Product descriptions from the supplier

Why Choose Us

图片关键词

Product Details

SL7N PV Series Circuit Breaker	SL7N-63
Frame degree rated current (A)	63A
Ue Rated operating voltage (V DC)	DC 550V	DC 800V	DC 1000V	DC 1200V
Rated Current In (A)	6-10-16-20-25-32-40-50-63
Rated insulation voltage Ui (V DC)	2P: 800V 4P:1200V
Rated Impact voltage Uimp (kV)	4
Ultimate breaking capacity lcu (kA)	6	6	6	6
Run breaking capacity lcs (%lcu)	75%	75%	75%	75%
Curve type	C
Trip type	Thermal-magnetic
MECHANICAL	20000
	8500
ELECTRIC	2500
	1500
Shunt release (SHT)	Option
Undervoltage release (UNT)
Auxiliary contact (AX)
Alarm contact (AL)
Wiring capacity (mm²)	In≤32A,1∼25mm²,1≥40A,10∼35mm²
Ambient temperature (℃)	-20∼70
Altitude	≤2000
Relative humidity	≤95%
Pollution Level	3
Installation Environment	No obvious shock and vibration
Installation category	Class lll
Installation	DIN Standard rail

Lable: Adjustable Dc Mcb
