Product descriptions from the supplier

Product Description

product name

DELTA VFD450C43S-00 C2000 Plus Series Vector Control Drive

Product Overview

The VFD450C43S-00 is a high-performance 45kW (60HP) AC drive from DELTA’s C2000 Plus Series, designed for industrial automation applications requiring precise speed, torque, and position control. Rated for 3-phase 460V input (380–480V ±15% tolerance), it supports sensorless vector control for induction motors (IM) and permanent magnet motors (PM), delivering 150% overload capacity for 60 seconds and 180% for 3 seconds. With IP20 protection and a compact design, this drive integrates seamlessly into control panels, making it ideal for heavy-duty environments like manufacturing, material handling, and process industries.

2. Technical Specifications

Power Range:

45kW (60HP)

Input Voltage:

380–480V AC (3-phase)

Output Frequency:

0–599Hz

Control Modes:

 Sensorless Vector Control (SVC), Field-Oriented Control (FOC), V/F Control

Communication:

Built-in RS-485 (Modbus RTU) + optional cards (EtherNet/IP, EtherCAT, Profinet, Devicenet)

Efficiency:

Up to 96% with regenerative braking capability

Certifications:


CE, UL, cUL, RoHS

Dimensions:

10.04” x 11.02” x 5.98” (255mm x 280mm x 152mm)
Weight: 63.8 lbs (29kg)

3. Design Features

The VFD450C43S-00 features a modular architecture with hot-swappable components (e.g., LCD keypad, I/O cards) for easy maintenance. Its built-in PLC (10k steps) enables standalone automation, reducing system complexity. The drive supports multi-axis synchronization and positioning control (via encoder feedback), while the class 3C3 conformal coating protects against dust and moisture. A dedicated STO (Safe Torque Off) function ensures safety in emergency stops, compliant with SIL 2/PL d standards.

4. Applications

Industrial Machinery:

Injection molding machines, extruders, conveyors.

HVAC Systems:

 Centrifugal pumps, fans, and chillers for energy-efficient climate control.

Material Handling:

Cranes, hoists, and AGVs requiring precise torque control.

Process Industries:

Chemical reactors, food processing lines, and water treatment plants.

Renewables:

Wind turbine pitch control and solar tracking systems.

5. Installation & Compatibility

Installed via wall-mounting or DIN rail, the drive interfaces with standard 3-phase motors and supports plug-and-play expansion modules (e.g., I/O, communication). It operates with mineral oil-based lubricants and is compatible with DELTA’s MCGS HMI panels for intuitive monitoring. For harsh environments, optional stainless-steel enclosures (IP66) are available.

6. Maintenance & Longevity

Routine maintenance includes filter replacement and fan inspection, with the drive’s self-diagnostic system alerting users to faults (e.g., overvoltage, overheating). The 2-year warranty covers defects in materials and workmanship, while remote monitoring via Delta’s WPLSoft software streamlines predictive maintenance. With proper cooling (ambient ≤50°C) and filtration, the drive achieves 100,000+ hours of operation.


7. Unique Advantages

Energy Efficiency:

 Built-in PID control and auto energy-saving mode reduce power consumption by up to 30%.

Flexibility:

 Supports 16-step speed control and S-curve acceleration/deceleration for smooth operation.

Safety:

STO function and phase loss protection prevent accidents and equipment damage.

Connectivity:

Seamless integration with IIoT platforms via OPC UA and MQTT protocols.

Cost Savings:

Eliminates external PLCs and reduces wiring complexity through CANopen master capabilities.
