Xtester-RS588 Cheap High Precise No Contact Ultrasonic Water Level Distance Sensor for Trash Bin With Lora Wan Connection

Main Features :
Serial No. : Lisa0866

Specification

Contact Us For Quotation

Email: 464560351@qq.com

Whatsapp&Wechat:+8618620373879

Xtester-RS588 Cheap High Precise No Contact Ultrasonic Water Level Distance Sensor for Trash Bin With Lora Wan Connection

Product description

Measurement parameters
Product Name	Ultrasonic Water level sensor with 3 meters measure range
Flow measurement system
Measuring principle	Ultrasonic sound
Applicable environment	24 hours online
Operating temperature range	-20℃~+70℃
Operating Voltage	DC 5V
Working current	Normal state< 20mA, Sleep state< 1mA
Working Frequence	40kHz
Max Measuring range	7.5 meters
Bland area	22cm
Ranging resolution	1mm
Ranging accuracy	±(1%Reading+10mm)
Output	RS485 modbus protocol
Detection period	100ms/Work Cycle
Detection angle	Horizontal direction: 1.7° (typical value); Vertical direction: 12°~29° (typical value)
Storage temperature range	-20℃~70℃
Protection level	IP65
Data transmission system
4G RTU/WIFI	optional
LORA/LORAWAN	optional
Application scenario
Application scenario	-Channel water level monitoring
	-Irrigation area -Open channel water level monitoring
	-Cooperate with standard weir trough (such as Parsell trough) to measure flow
	-Water level monitoring of the reservoir
	-Natural river water level monitoring
	-Water levelmonitoring of underground pipe network
	-Urban flooding water level monitoring
	-Electronic water gauge

Lable: RS588 Distance Sensor
